1. CNC 6-side drilling machine

Open a new model of customized furniture production

The manufacturing machinery on the furniture manufacturing production line mainly includes cutting machines, drilling machines, panel saws, edge banding machines, etc. Drilling is a crucial link, but drilling has always been a difficult point in the process.

It can be said that without CNC 6-side drilling machine , there might not be customized home furnishing industry 4.0. The emergence of CNC 6-side drilling has greatly saved production time and helped customized furniture companies improve production efficiency and increase production capacity! The CNC 6-side drilling machine can complete 6-side drilling at high speed. The machine can clamp the wood workpiece and complete the processing of all holes on the front, back and four side holes at one time. There is no need for manual intervention to turn the plate, and the shape and milling can be formed in one go.

With the continuous updating and upgrading of CNC equipment, CNC 6-side drills are getting more and more attention and favor from customized furniture manufacturers. Different from six-row drilling and side hole machines, CNC 6-side drilling can position and process holes and grooves on all sides at one time, with very high precision and high processing speed. CNC 6-side drill, the minimum processing plate width is 50mm, the maximum plate processing width is 1220mm, and the maximum processing plate thickness is 50mm.

The CNC 6-side drill is mainly used for horizontal and vertical drilling and groove processing of various types of artificial boards, solid wood boards, and semi-solid wood boards. It is a CNC processing equipment with simple operation, fast drilling processing speed, and a small spindle. Slotting, suitable for processing various combination cabinets and panel furniture. CNC 6-side drill is one of the most practical equipment among customized panel furniture manufacturers, which can realize mass production or customized production of multiple varieties.

Building smart factories and realizing flexible customization and intelligent production lines will become the basis for the survival of furniture companies. Today, the CNC 6-side drill is an indispensable machine in the smart manufacturing factory line. Tuodiao CNC actively responds to the national intelligent manufacturing "2025" and "14th Five-Year Plan" calls to promote the automation of customized furniture in China. From automatic warehousing, automatic material preparation, automatic labeling, automatic cutting, edge sealing and connection, automatic punching, as well as automatic sorting, packaging and finished product warehouse, the whole process of data interconnection and visualization, the board does not fall to the ground, minimizing manual intervention.

2.Tuodiao CNC 6-side drilling machine

Multiple flexibility and new acceleration

Tuodiao CNC launched the domestic dual-channel six-drill package and 6-side drill in March 2021, and has made technological breakthroughs in many aspects such as the frame, row drilling package, gripper and CNC system. So, compared with four-sided and five-sided drills, what are the main advantages of engraving CNC 6-side drills? First, the degree of automation is higher; second, the drilling accuracy is higher. In addition, it is easier to operate and has a wider range of applications.

2.1 High degree of automation

The 6-side engraving drill can be processed by scanning the code and placing the board. It can complete the 6-side drilling (front, back, left, right, front, and back) and front and back grooving of the board at one time. Used in conjunction with a CNC cutting machine, it greatly improves production efficiency and can produce more than 1,000 pieces of small boards in a single shift.

With the advantages of integrated frame, intelligent gripper, customized drilling package, dynamic special-shaped positioning, and customized 3D home control system, the double-drill usage efficiency of Tuodiao 6-side drill can be increased to 90%, and the drilling efficiency reaches 4.8-6.3pcs/min, the processing efficiency of the whole machine is 30%-40% higher than similar products on the market on average.

2.2 High drilling accuracy

The 6-side engraving drill uses CNC drilling. The minimum processing distance for vertical holes with double drills and horizontal drilling is 60mm. The minimum processing distance for vertical double drilling and horizontal drilling is 128mm. The minimum processing distance for horizontal double drilling and horizontal drilling is 210mm. And it has 12pcs built-in auxiliary pressure wheels to ensure the accuracy of hole position to the greatest extent.

In addition, the operation of engraving a 6-side drill is simple. In conjunction with the CNC 6-side drill production, the CNC cutting machine does not require manual turning of the material, and ordinary workers can learn it in one day, which greatly improves production efficiency and saves labor costs. Tuodiao CNC 6-side drill can not only connect to CNC cutting machines and electronic cutting saws, but also match various data formats such as BAN, DXF, XML, MPR, etc. It can be connected to all mainstream software on the market, and the processing efficiency is high, high precision.

Moreover, Tuodiao CNC 6-side drill is suitable for processing and drilling holes in various types of artificial boards, solid wood boards and other materials. It can be widely used in customized furniture, panel furniture, cabinets and wardrobes, office furniture, doors, etc. Tuodiao CNC can provide customers with a complete set of solutions to help 6-side drilling equipment perform at a high level, operate stably, and achieve efficient production.

Tuodiao CNC 6-side drill products include double-drill packaged CNC 6-side drill, three-drill packaged CNC 6-side drill, three-drill packaged dual-station 6-side drill, multi-functional automatic tool changer 6-side drill, and four-drill packaged duplex. position, dual-channel 6-side drilling, six-drilling package dual-channel 6-side drilling, etc., which are highly matched to the needs, meet the needs of different scenarios, and are of great help to improve efficiency. Moreover, the price of Tuodiao CNC 6-side drill products is less than 50% of that of leading foreign brands. The good product performance and more competitive prices have led many domestic leading home furnishing companies to choose Tuodiao CNC drilling equipment. Tuodiao CNC continues to make efforts to help customized furniture companies achieve Industry 4.0 production transformation.

Adhering to the attitude of ingenuity and excellence in cultivating 6-side drill, this is the reason why Tuodiao CNC 6-side drilling have superior quality and why they have won unanimous praise from the market. With strong market competitiveness and good market reputation, Tuodiao CNC will continue to establish cooperation with more new high-quality customers to ensure its long-term sustainable business development.

At the same time, Tuodiao CNC will continue to increase investment in R&D, expand production scale, strengthen brand, marketing and key customer strategies, vigorously increase market share, and strive to become a professional CNC complete solution provider to help the furniture manufacturing industry reach a higher level Floors.
